Nantong Drayson Composite Material Co., Ltd. is one of the leading manufacturers and suppliers of fiberglass u channel in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Contact us for more details.

Parameters
Type	Fiberglass U Channel
Material	ECR Glass Fiber + Resin (ORTHO,ISO,VE,PHENOLIC)+Filling (ATH)
Size	Can be customized (pls check detail as below form)
Color	According to RAL Book.Yellow, Orange, Blue, Green, Grey, etc. can be cutomized

Pultruded FRP section features:

1.Lightweight and high strength

2.Good looking, corrosion-resistant

3.Free maintenance, fire retardant, anti-UV

4.Excellent insulation, magnetic permeability

5.Any color, length, and specifications

6.Easy and quickly installation or cut

Size

Item	Size AxBxT1xT2(mm)
C25	25x14x3.0x3.0
C31	31x25x4.0x4.0
C40	40x24x3.2x3.2
C45	45x28x4.0x6.4
C50	50x14x3.2x3.2
C70	70x30x4.5x4.5
C75	75x35x5.0x5.0
C76	76x22x6.4x6.4 , 76x38x6.4x6.4
C90	90x35x8.0x8.0
C102	102x27x3.2x3.2 , 102x29x4.8x4.8 102x44x4.8x4.8 , 102x44x6.4x6.4
C120	120x25x5.0x5.0 , 120x30x5.0x5.0 120x40x5.0x5.0 , 120x40x5.0x5.0
C145	145x25x5.0x5.0
C150	150x8x3.5x3.5 , 150x100x6.4x6.4
C152	152x42x4.8x4.8 , 152x42x6.4x6.4 152x42x9.5x9.5 , 152x50.8x9.5x9.5
C160	160x48x8.0x8.0
C203	203x56x6.4x6.4 , 203x56x9.5x9.5 203x102x12.7x12.7
C210	210x55x5.0x5.0 , 210x80x5.0x5.0 210x85x5.0x5.0
C240	240x72x8.0x8.0 , 240x115x5.0x5.0
C254	254x70x12.7x12.7
C260	260x76.2x12.7x12.7
C290	290x70x12.7x12.7
C310	310x115x5.0x5.0
C381	381x90x10.0x10.0
C436	436x90x10.0x10.0
C491	491x12x90x10.0
C902	902x100x10.0x10.0
C970	970x40x10.0x10.0
