● Introduction
Molded and Fiberglass Heavy-Duty Grating is high strength and designed specifically to carry heavy-duty load such as rolling loads from forklifts, and to support vehicular traffic including transport trucks and motors, it`s much more strong than normal molded FRP grating, and can act as traditional metal grating.
Drayson Composite offers ECR glass fibers and four kinds of resin for choice
Orthophthalic (Ortho) | Ortho resin is resistant to atmospheric corrosion. |
Isophthalic (ISO) | ISO resin is suitable for a corrosive and chemical environment and is highly fire-resistant with controlled spreading of smoke. |
Vinylester (VE) | VE is resistant to chemicals, such as acids, salts, and other corrosive substances. This type of resin is also highly fire-resistant. |
Phenolic | Phenolic resin is resistant to chemicals and is extremely fire- resistant and gives off very little smoke. |
● The Advantages
● High Strength
● Corrosion resistance
● Fire retardant
● Non-conductivity
● Low maintenance
● Heavy Load Support
● Application
The fiberglass heavy-duty grating can be used as:
● Forklift Rolling Loads
● Storage Place
● Flooring
● Industrial Platforms
● Long Span Walkways
● Support vehicular Traffic
● Different surface kind of
The thickness of fiberglass heavy duty grating is usually in 50mm, 60mm and 70mm, the 50mm is most popular.
● Sizes
Mesh Size (mm) | Thickness (mm) | Bar Thickness (mm) | Standard Panel Size(mm) |
38x38 | 50 | 9.5/7.5 | 1220x4010,1220x3666,1230x4010,1220x2440,921x3055 |
60 | 10.5/8.5 | 1230x4010 | |
70 | 11.0/9.0 | 1230x4010 | |
50x50 | 50 | 8.0/6.0 | 1524x4000,1220x3660,1220x2440,1220x4000 |
25x50 | 50 | 12.0/9.0 | 1220x1835 |
