Nantong Drayson Composite Material Co., Ltd. is one of the leading manufacturers and suppliers of fiberglass bar grating in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Contact us for more details.

Fiberglass Bar Grating is high-strength grate that performs well in corrosive environments or where a lightweight grating is preferable. Fiberglass Grating pultrusions come in three categories: I-Shape bars, T-Shape bars, and High-Load bars for Heavy-Duty Applications. The bearing bars are interconnected with cross-rods every 152mm or 305mm.


T-shape type	High-load bars	I-shape type

Material	ECR Glass Fiber + Resin (ORTHO,ISO,VE,PHENOLIC)+Filling (ATH)
Application	Safe deck,Agriculture,Factories,Industries,Platforms walkways trench,Constrution,Pollution Control,Fire Equipment,Breweries,Mining,Chemical,Oil and Gas,Marine.
Certification	ISO14001/ISO19001

The Advantages of Fiberglass Bar Grating

Corrosion-resistant;

Fire-retardant;

Anti-slip;

Lightweight;

Heavy-Duty & High Strength;

Maintenance-free;

Not electrically conductive;

Easy cutting & installation.

Size

Item	Height(mm)	Upper Width(mm)	space distance(mm)	gap width(mm)
I-1410	25	15	25	10
I-5010	25	15	30	15
I-6010A	25	15	38	23
I-6010B	25	8	19.8	11.8
I-4015	38	15	25	10
I-5015	38	15	30	15
I-6015	38	15	38	23
I-4012	30	15	25	10
I-5012	30	15	30	15
I-6012	30	15	38	23
I-40125	32	15	25	10
I-50125	32	15	30	15
I-60125	32	15	38	23
I-4020	50	15	25	10
I-5020	50	15	30	15
I-6020	50	15	38	23
T-1210	25	38	43.4	5.4
T-1810	25	38	50.8	9.5
T-2510	25	38	50.8	12.7
T-3310	25	41.3	19.7	61
T-3810	25	38	61	23
T-1215	38	38	43.3	5.2
T-2515	38	38	50.8	12.7
T-3815	38	38	61	23
T-3320	50	25.4	38.1	12.7
T-5020	50	25.4	50.8	25.4
HL-4020	50	15	10	10
HL-5020	50	15	15	15
HL-6020	50	15	23	23
