Nantong Drayson Composite Material Co., Ltd. is one of the leading manufacturers and suppliers of frp flat strip in China. With abundant experience, we warmly welcome you to buy high quality customized products at competitive price from our factory. Contact us for more details.
Introduction
FRP flat bars are manufactured using pultrusion process. Glass mat and roving are drawn through a resin bath and pulled through a heated die to form the desired shape.
Fiberglass flat bar/ fiberglass strip are manufactured by combining various resins with pure glass fibre reinforcement. They are formed and cured in a continuous process creating a product of extraordinary strength and resilience. The resultant fibreglass pultruded profiles offer a combination of benefits and mechanical properties exceeding those of metal. Manufactured from pultruded fibreglass products and can be supplied in channel, I-bean, box, angle , tube , small rods sections for the construction of chemical resistant plant assemblies, amusement and agriculture .
Features
 | Light Weight,high strength |
High dimensional stability,easy to fabricate install | |
Colorful,beautiful in aesthetics | |
Electrically insulating,flame retardant | |
Ageing resistance |
Size
| Type | Dimension(mm) |
Flat plate/panel | A*T | |
FP32 | 3.2x1220 | |
FP64 | 6.4x1220 | |
FP95 | 9.5x1220 | |
FP127 | 12.7x1220 | |
FT152 | 15.2x1220 | |
FT190 | 19x1220 | |
Flat strip | A*T | |
FS19 | 19x6.4 | |
FS30A | 30x3.0 | |
FS30B | 30x6.4 | |
FS35 | 35x8.0 | |
FS38 | 38x5.0 | |
FS40 | 40x8.0 | |
FS50B | 50x4.0 | |
FS50C | 50x8.0 | |
FS50D | 50x15 | |
FS50E | 50x17 | |
FS102 | 102x5.0 | |
FS152 | 152x20 | |
FS190 | 190x15 | |
FS280 | 280x10 | |
FS50A(bevel edge) | 50x3.2 | |
FS60A(bevel edge) | 60x3.2 | |
FS70(bevel edge) | 70x4.0 | |
FS90A(bevel edge) | 90x3.2 | |
FS100(bevel edge) | 100x3.2 | |
FS120(bevel edge) | 120x3.0 |
